S2646/S3246 Repair Parts – 25
1 127076 2 GRIP PLASTIC HANDLE GRIP BLACK
2 302544 8 PIN SNAPPER W/ LNYD .375X2.25
3 0360992 2 TUBE TELESCOPING EXT DECK HND
4 0371605 1 WLDMT HAND RAIL RH SIDE
5 0371606 1 WLDMT HANDRL LH SIDE
6 0371608 1 WLDMT HANDRAIL ROLLOUT
7 0371626 2 WLDMT HANDRL TOE BOARD (omitted on CE)
0372003 2 WLDMT HANDRL TOE BOARD (CE only)
8 0371637 1 WLDMT HANDRL ROLLOUT HINGE CORNER
9 0371639 1 WLDMT HANDRL ROLLOUT CORNER
10 0371776 2 TUBE HANDRL MOUNT LG E-DECK (omitted on CE)
0372005 2 TUBE HANDRL MOUNT LG E-DECK (CE only)
11 0371814 1 WLDMT PLATF DECK
12 0371815 1 WLDMT PLATF ROLLOUT
13 0371823 4 ROLLER ROLLOUT DECK
14 0371824 2 ROLLER PLATF OUTER
15 1 UPPER CONTROL BOX ASSY S26/3246 (see Repair Parts and Electrical sections)
16 0371927 2 PL EXT DECK BRACKET (omitted on CE)
0372002 2 PL EXT DECK BRACKET (CE only)
17 0371931 2 TOP SLIDE RAIL
18 0371934 2 SLIDE RAIL WELDMENT
19 0371935 2 TUBE HAND RAIL
20 0371937 2 PIN DETENT
21 0371940 2 HANDLE WELDMENT
22 0371981 1 TOE KICK, RH ENTRY (omitted on CE)
23 0371984 1 TOE KICK, LH ENTRY (omitted on CE)
0372017 1 TOE KICK, ENTRY (CE only)
24 454996 4 SPRING
25 466414 2 HOUSING, DETENT PIN
26 468886 6 END CAP 1.25 SQ PLASTIC BLACK
27 969989 2 BLT HEXHD .250-20 1.75 GR5
28 970169 2 BLT HEXHD .250-20 2.00 GR5
29 970179 2 BLT .250-20 2.50 GR5
30 970239 4 BLT HEXHD .313-18 .750 GR5
31 970309 20 BLT .313-18 2.25-GR. 5
32 970319 4 BLT HEXHD .313-18 2.50 GR5
33 970539 2 BLT .375-16 2.75-GR 5
34 970569 2 BLT HEXHD .375-16 3.50 GR5
35 984339 2 NUT JAM .250-28
36 986019 12 WASHER FLAT .250
37 986269 44 WASHER FLAT .313
38 986299 4 WASHER FLAT .375
39 989569 4 SPIRAL PIN .375 DIA X 1.75
40 2610001 2 YOKE 1/4-28 FEM SAE J493
41 5560004 6 NUT LKG .250-20
42 5560031 28 NUT LKG .313-18
43 5560033 4 NUT LKG .375-16
44 5569973 10 WEAR PAD
Platform
Item Part No. Qty. Description
To Next Page
