アイテム 部品番号 名前 数量 UOM
Not
Shown
514483-001 UPPERCONTROLPANEL
ASSEMBLY-ANSI
EA
1 514484-000 A38lowercontrolpanel 1 EA
2 510471-000 JOYSTICK(BeforeSNSL30-01-
XXXX00061/SL26-01-
XXXX000017)
1 EA
2 13888 JOYSTICK,JRMERRITTWITH
GUARD(HALLEFFECT)JULY
2017ANDAFTER
1 EA
3 512934-000 LEDRED12V 2 EA
4 512935-000 LEDGREEN12V 4 EA
5 510542-000 PUSHBUTTONBLACKC/W1
N/OCON
2 EA
6 510524-000 PUSH/PULLSWASSYW/NC
CONTACT
1 EA
7 514132-000 BOOT 5 EA
8 510521-000 GROUNDOPSWITCH(ENABLE) 5 EA
9 514491-000 Contactbase1N/O1N/C 1 EA
10 514490-000 Switchhead3-way
stayput/springtocentre
1 EA
11 514485-000 SLUCBenclosure 1 EA
12 056066-005 NutNylockNutDIN985M58.0Zi 4 EA
13 056069-005 WasherSteelFlatWasher
DIN125A
8 EA
14 058501-025 M5x25S.H.C.S.-GR12.9 4 EA
15 058501-016 M5x16S.H.C.S.-GR12.9 4 EA
16 502588-000 ALARM,ECCOBEEPING6-28VDC 1 EA
17 510472-000 Matrixboard(BeforeSNSL30-
01-XXXX00061/SL26-01-
XXXX000017)
1 EA
17 3030169 Matrixboard(AfterSNSL30-01-
XXXX00062/SL26-01-
XXXX000018)
1 EA
18 510157-000 12waypanelplug 2 EA
19 510156-000 9WAYPANELPLUG 1 EA
SL26SL SL30SL PARTS MANUAL UPPER CONTROL PANEL ASSEMBLY - ANSI
UPPER CONTROL PANEL ASSEMBLY - ANSI
Tue Feb 16 03:29:19 UTC 2021 2-26
