Page 22
SL26/30SL
ILLUSTRATED PARTS LIST
CONTROL MODULE ASSEMBLY
ITEM PART DESCRIPTION QTY
1 302-0049 Switch, battery
disconnect
1
2
514487-000 LCB CE 1
514487-001 LCB ANSI 1
3 510505-000 Cover, hydraulic hoses 1
5 510588-005 M5, plain washer 6
6 510588-006 M6, plain washer 8
7 510588-008 M8, plain washer 10
8 510588-010 M10, plain washer 3
9 510593-012 Pan head screw, M5 x
12 mm
2
10 13-2367 Manifold tank line drain 1
11 510567-025 CSK socket head
screw, M6 x 25 mm
1
12 058490-025 Bolt, M5 x 25 mm 4
13 058491-016 Bolt, M6 x 16 mm 5
14 058491-020 Bolt, M6 x 20 mm 2
16 510477-000 Stand, manifold
mounting
8
17 058492-025 Bolt, M8 x 25 mm 8
18 056060-050 Bolt, M10 x 50 mm 3
19 PCA015 Rubber channel
section
1
20 056066-005 Nut, M5 nylock 6
21 056066-006 Nut, M6 nylock 8
22 056066-008 Nut, M8 nylock 8
23 056064-010 Nut, M10 nylock 3
24 3618-26 Hose clamp, 26 - 28
mm
1
25 3618-32 Hose clamp, 34 - 37
mm
1
ITEM PART DESCRIPTION QTY
*26 515272-000 Top plate control
cabinet
1
27 12716-14 Cabinet support 1
28 8342416 Latch, adjustable
trigger
1
29 3040269 Rubber boot cable end 4
30 300840 Lock out lever
assembly
1
31 502197-000 M8 x 300 hook bolt 2
32 064040-000 Angle battery hold
down
1
33 11470 Left hand hinge 2
34 11470-1 Right hand hinge 2
35 11558 Hydraulic oil tank
assembly
1
36 062299-002 Battery, 12 V 1
37 11679 Left hand door weld,
small
1
38 11680 Right hand door weld,
large
1
40 514721-000 Manifold drive control 1
41 514720-000 Manifold movement
control
1
*42 515284-000 Control cabinet weld 1
43 5560179 Flat washer, special 3
44 058492-020 Bolt, M8 x 20 mm 2
45 056021-008 M8, spring washer 2
46
508078-001 Filter assembly 1
508078-000 Filter 1
508078-002 Filter head 1
47 503789-002 Emergency down cable 1
Table 6-11: SL26/30SL
* Tunnel Option Parts
Rep Page 6-16
