SL26/30SL
ILLUSTRATED PARTS LIST
PLATFORM ASSEMBLY SL26 - SLIDE OUT SECTION
ITEM PART DESCRIPTION QTY
1 064785-000 Side rail 2
2
*3 515388-000 Front rail 1
4 064763-000 Deck weldment (Be-
fore SN SL26SL-01-
xxxx00092)
1
4 515824-000 Deck Slide Out
Weldment (After SN
SL26SL-01-xxxx00093)
1
5 064761-000 Floor (Aluminium) 1
6 063727-000 Block 4
7 064233-000 Wheel (narrow) 4
8 064234-000 Wheel (wide) 2
9 064235-000 Washer 4
10 064776-000 Tube, rail support 2
11 064425-000 Slide bracket (Be-
fore SN SL26SL-01-
xxxx00092)
4
11 515825-000 Slide Bracket (After SN
SL26SL-01-xxxx00093)
4
12 063990-003 Axle 2
13 064249-000 Bushing (spanner) 2
14 064256-000 Bearing strip 1
15 064795-000 Gusset plate (Be-
fore SN SL26SL-01-
xxxx00092)
2
15 515827-000 GUSSET, RH (After SN
SL26SL-01-xxxx00093)
2
15 515826-000 GUSSET, LH (After SN
SL26SL-01-xxxx00093)
2
16 064267-000 Bumper pad 4
17 003570-001 Retaining pin assembly 2
18 064774-000 Roller bracket 2
19 064769-001 Right handle 1
20 064769-002 Left handle 1
21 064773-000 Handle bracket 2
22 026553-008 Pop rivet - 3/16
diameter 1/2 - 5/8 grip
12
23 026553-002 Pop rivet - 3/16
diameter 1/8 - 1/4 grip
30
24 011240-004 Flat washer 1/4
standard
22
ITEM PART DESCRIPTION QTY
25 064240-001 Bushing 2
26 011254-018 Screw - Cap 3/8 - 16 x
2 1/4
4
27 011254-032 Screw - CAP 3/8 - 16
x 4
2
28 011254-010 Screw - CAP 3/8 - 16
x 1 1/4
10
29 067685-000 Spacer 2
30 011248-004 Locknut - 1/4 - 20 22
31 011252-014 Screw - 1/4 - 20 UNC
hex hd x 1 3/4
10
32 011248-006 Locknut - 3/8 - 16 26
33 011240-006 Flat washer 3/8 stand-
ard
12
34 064775-000 Front angle 2
35
36
37 011240-002 Washer #8 6
38 064247-000 Guide slide 3
39 011254-020 Screw - cap 3/8 - 16 x
2 1/2
6
40 011252-016 Screw - cap 1/4 - 20
x 2
4
41 011252-006 screw - cap 1/4 - 20
hex hd x 3/4
2
42 066550-006 Decal - danger 1
43 066551-003 Decal - danger 1
44
45 011254-008 Screw - 3/8 - 16 hex
hd x 1
4
46 064688-001 Bracket - toe board
pivot right hand
1
47 064688-002 Bracket - toe board
pivot left hand
1
48 101251-001 Decal - danger tip over 1
* Option Parts
Rep Page 6-10
