Snorkel SL26-01 Series User Manual

アイテム 部品番号 名前 数量 UOM
Not
Shown
505602-000 ELEVATINGASSEMBLYSL26RTE EA
1 011254-024 Bolt,Pinlock3/8 9 EA
2 064090-000 Pivotpin,upperT-bar&upboom
-PED
3 EA
3 011248-006 Locknut-3/8-16 9 EA
4 064111-001 Pedestalweldment(BeforeSL26-
01-00066)
1 EA
4 513285-000 Pedestalweldment(AfterSL26-
01-00090+inc.
00067,00074,00073)
1 EA
5 062649-020 Bushing,all1.75pins 12 EA
6 064087-000 Uppertensionbar(BeforeSL26-
01-00066)
1 EA
6 513289-000 Uppertensionbar(AfterSL26-
01-00090+inc.
00067,00074,00073)
1 EA
7 064078-002 Upperboom(BeforeSL26-01-
00066)
1 EA
7 513255-000 Upperboom(AfterSL26-01-
00090+inc.
00067,00074,00073)
1 EA
8 064451-000 Channel,wirecover(upper
boom)
1 EA
9 062642-030 Bushing,all2.75pins 6 EA
10 011248-016 Nut(roller) 6 EA
11 064089-000 Gearsegment 2 EA
12 013336-001 FITTING,GREASE 16 EA
13 064070-002 2ndPostweldment(BeforeSL30-
01-00168/SL26-01-00066)
1 EA
13 513219-000 2ndPostweldment(AfterSL30-
01-00177+inc.00169,00173/
SL26-01-00090+inc.
00067,00074,00073)
1 EA
14 064094-000 Pivotpin,cylinderbody-1stpost 2 EA
15 062649-010 Flangedbushing 2 EA
16 011248-016 Nut(roller) 1 EA
SL26SL SL30SL PARTS MANUAL ELEVATING ASSEMBLY SL26SL
ELEVATING ASSEMBLY SL26SL Tue Feb 16 03:29:17 UTC 2021 2-16
