アイテム部品番号名前数量 UOM

Not

Shown

505502-000 ELEVATINGASSYSL30SL EA

1 011254-024 Bolt,Pinlock3/8 9 EA

2 064090-000 Pivotpin,upperT-bar&upboom

-PED

3 EA

3 011248-006 Locknut-3/8-16 9 EA

4 064111-002 Pedestalweldment(BeforeSL30-

01-00168)

1 EA

4 513237-000 Pedestalweldment(AfterSL30-

01-00177+inc.00169,00173)

1 EA

5 062649-020 Bushing,all1.75pins 12 EA

6 064536-000 Uppertensionbar(BeforeSL30-

01-00168)

1 EA

6 513247-000 Uppertensionbar(AfterSL30-

01-00177+inc.00169,00173)

1 EA

7 064521-000 Upperboom(BeforeSL30-01-

00168)

1 EA

7 513182-000 Upperboom(AfterSL30-01-

00177+inc.00169,00173)

1 EA

8 064538-000 Channel,wirecover(upper

boom)

1 EA

9 062642-030 Bushing,all2.75pins 6 EA

10 011248-016 Nut(roller) 6 EA

11 064089-000 Gearsegment 2 EA

12 013336-001 FITTING,GREASE 16 EA

13 064070-002 2ndPostweldment(BeforeSL30-

01-00168/SL26-01-00066)

1 EA

13 513219-000 2ndPostweldment(AfterSL30-

01-00177+inc.00169,00173/

SL26-01-00090+inc.

00067,00074,00073)

1 EA

14 064094-000 Pivotpin,cylinderbody-1stpost 2 EA

15 062649-010 Flangedbushing 2 EA

16 011248-016 Nut(roller) 1 EA

17 064095-000 Pivotpin,lowerboom&upper

boom-2nd

3 EA

SL26SL SL30SL PARTS MANUAL ELEVATING ASSEMBLY SL30SL

ELEVATING ASSEMBLY SL30SL Tue Feb 16 03:29:17 UTC 2021 2-17
