ATYSp - 542001E - SOCOMEC
AnnexeII-28.1.Detailledevents
Function 6 and 16 Codes
• Command Zone R1
NOTE: When zone R1 is completed with value 1, zone R2 automatically ls in with the last saved value. At the end
of this operation, writing 0xFFFE in zone R1 enables the reading of the next data.
Dec.
Address
Hex.
Address
Words
count
Description Unit
24320 5F00 1 Action
0x0001: Reset read pointer
0xFFFE: Get next data
24321 5F01 1 Filtering action - If not written, no ltering is done
To use ltering, entire table should be written in one time with
function 16
0x00XX: only get events in the form XXyy
0xFFFF: no lter
Function 3 Codes
• Data Zone R2
Dec.
Address
Hex.
Address
Words
count
Description Unit
24336 5F10 1 record count
If record count == 0xFFFF, it means that ltering process is not
done now, so the reader has to re-read the table to get the
values.
24337 5F11 1 record size
If record size == 0xFFFF, it means that ltering process is not
done now, so the reader has to re-read the table to get the
values.
nb words
120 8 * Event data record
