Function 3 Codes
• Data record description
Dec.
Address
Hex.
Address
Words
count
Description Unit
0 0 1
Event ID
0x8000: Power On
0x8001: Power Off
0x8100: Conguration changed
0x8101: Conguration save failed
0x8102: Conguration load failed
0x8105: Conguration date saved
0x8106: Conguration date save failed
0x8107: Conguration date read failed
0x8110: Conguration calibration read failed
0x8300: User reset
0x8301: Watchdog reset
0x8302: Date resynchronized
0xFF00: Software version changed
0x0001: Source 1 Lost
0x0002: Source 1 comes back
0x0003: Source 1 not started (1ST / 2ST)
0x0004: Source 1 Undervoltage
0x0005: Source 1 Overvoltage
0x0006: Source 1 Unbalanced
0x0007: Source 1 Underfrequency
0x0008: Source 1 Overfrequency
0x0009: Source 1 Rotation fault
0x000A: Source 1 Neutral fault
0x000B: External fault with zero return source 1
0x000C: External fault without zero return source 1
0x000D: Source 1 Overload
0x0101: Source 2 Lost
0x0102: Source 2 comes back
0x0103: Source 2 not started (2ST)
0x0104: Source 2 Undervoltage
0x0105: Source 2 Overvoltage
0x0106: Source 2 Unbalanced
0x0107: Source 2 Underfrequency
0x0108: Source 2 Overfrequency
0x0109: Source 2 Rotation fault
0x010A: Source 2 Neutral fault
0x010B: External fault with zero return source II
0x010C: External fault without zero return source II
0x010D: Source 2 Overload
0x0201: Test on load start
0x0202: Test on load end
0x0203: Test on load failed
0x0204: Test off load start
0x0205: Test off load end
0x0206: Test off load failed
0x0207: External order on load start
0x0208: External order on load end
0x0209: External order on load failed
0x020A: External order off load start
0x020B: External order off load end
0x020C: External order off load failed
0x020D: Battery charger start
0x020E: Battery charger end
0x020F: Unlimited TOF/TON stopped because of communication
timeout
0x0301: Automatic switch to position 0
0x0302: Automatic switch to position I
0x0303: Automatic switch to position II
0x0304: Manual switch to position 0
