TIMERS VALUE
Definition AdjustmentRange M-G M-M
E2T UNL
External Order Test On Load Limited (LIM) / Unlimited
(UNL) duration. LIM is to be selected when associating
the test to a duration timer such as E2T below. When
set to UNL, the test on load duration timer is deactivated
as the duration becomes unlimited.
Note 1: If the value is set at UNL, the TOT is stopped
either when the input is opened, or via the validation key.
Note 2: E2T is visible in the timers menu when at least
1 input is configured as EON.
LIM (Limited)
UNL (Unlimited)
•
E2T 0010 SEC
External Order Test On Load - Duration Timer: This timer
starts counting when the Test is initiated.
Note: E2T duration timer is visible in the timers menu
when at least 1 input is configured as EON and with
E2T (UNL/LIM) set to LIM.
0 – 1800 seconds •
E3T 0005 SEC
External Order Test On Load – End Delay Timer: This time
delay starts counting at the end of E2T Timer. The return
to the main supply takes place at the end of E3T time.
Note: E3T duration timer is visible in the timers menu
when at least 1 input is configured as EON and with
E2T (UNL/LIM) set to UNL.
0 – 1800 seconds •
E5T 0005 SEC
External Order Test Off Load - Start Delay Timer. This
time delay starts at the same time as the External On
Load (EOF) order is received. At the end of this time
delay, the Genset start order is activated. The load will
not be transferred to the Genset supply.
Note: E5T is visible in the timers menu when at least
1 input is configured as EON.
0 – 1800 seconds •
E6T LIM
External Order Test Off Load Limited (LIM) / Unlimited
(UNL) duration. LIM is to be selected when associating
the test to a duration timer such as E6T below. When
set to UNL, the test off load duration timer is deactivated
as the duration becomes unlimited.
Note 1: If the value is set at UNL, E5T is stopped either
when the input is opened, or via the validation key.
Note 2: E6T is visible in the timers menu when at least
1 input is configured as EOF.
LIM (Limited)
UNL (Unlimited)
•
E6T 0600 SEC
External Order Test Off Load - Duration Timer: This timer
starts counting when the Test is initiated.
Note: E6T is visible in the timers menu when at least
1 input is configured as EOF.
0 – 1800 seconds •
E7T 0005 SEC
External Order Test On Load – End Delay Timer: This
time delay starts counting at the end of E6T Timer. The
Genset signal will switch at the end E7T.
Note: E7T is visible in the timers menu when at least
1 input is configured as EOF.
0 – 1800 seconds •
LST 0004 SEC
Load Shedding - Time Delay (before transfer) Timer. This
time delay corresponds to the time available to perform
any load shedding operations downstream before the
ATyS switch to positionII.
Note: The ATS can switch to position 0 but will not
switch to the alternative source until LST has reached
zero.
0 – 60 seconds • •
EET 0168 H
S2 maximum reset timer - Battery Charger maximum
Off Timer. This timer denes, the minimum time that the
Genset must be switched off for output EES (Battery
Charger Signal) to be activated.
0 – 168hrs •
