socomec ATyS r User Manual

93
EN
ATYSp - 542001E - SOCOMEC
5
TIMERS VALUE
Definition AdjustmentRange M-G M-M
EDT 0000 SEC
S2 Run Timer - Battery Charger run timer. 0 – 9999 seconds •
Note:
It is recommended congure the inputs and outputs before the timers. All timers used with programmable outputs will only be
active and visible to set the timings after the associated output has been congured.
AnnexeI-11.I/OMenu–Keypadnavigation
6
I-O
Definition AdjustmentRange M-G M-M
IN 1 --- NO
Internal: Programmable Input number 1 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 2 --- NO
Programmable Input number 2 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 3 --- NO
Programmable Input number 3 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 4 --- NO
Programmable Input number 4 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 5 --- NO
Programmable Input number 5 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 6 --- NO
Programmable Input number 6 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 7 --- NO
Programmable Input number 7 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 8 --- NO
Programmable Input number 8 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN 9 --- NO
Programmable Input number 9 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN10 --- NO
Programmable Input number 10 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN11 --- NO
Programmable Input number 11 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
