socomec ATyS r User Manual

94
EN
ATYSp - 542001E - SOCOMEC
6
I-O
Definition AdjustmentRange M-G M-M
IN12 --- NO
Programmable Input number 12 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN13 --- NO
Programmable Input number 13 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
IN14 --- NO
Programmable Input number 14 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 1 POP NO
Programmable Output number 1 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 2 --- NO
Programmable Output number 2 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 3 --- NO
Programmable Output number 3 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 4 --- NO
Programmable Output number 4 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 5 --- NO
Programmable Output number 5 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 6 --- NO
Programmable Output number 6 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 7 --- NO
Programmable Output number 7 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 8 --- NO
Programmable Output number 8 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
OUT 9 --- NO
Programmable Output number 9 Normally Open /
Normally Closed: Refer
to the list below for Input
type details.
• •
AnnexeI-11.1.Programmableinputs
There are 6 internal programmable inputs built into the ATS controller as standard. External programmable inputs (up
to 8) are the optional add-on I/O modules that may be xed to the ATS controller using slots 1 to slot 4.
The list of available inputs is selected from the following options below. Depending on user requirements, the same
function may be applied to more than 1 input.
