Part 4．
．．
．Modbus resgiter Map
Function code
04 to read input parameters
Address
(Register)
Parameter
Number
Input Register Parameter
Modbus Protocol
Start Address
Hex
3
Ø
3
Ø
1
Ø
Parameter
unit
Hi byte Lo
byte
4
W
3
W
2
W
30001 1
Phase 1 line to neutral volts.
Volts 00 00 √ X √
30003 2
Phase 2 line to neutral volts.
Volts 00 02 √ X X
30005 3
Phase 3 line to neutral volts.
Volts 00 04 √ X X
30007 4
Phase 1 current.
Amps 00 06 √ √ √
30009 5
Phase 2 current.
Amps 00 08 √ √ X
30011 6
Phase 3 current.
Amps 00 0A √ √ X
30013 7
Phase 1 power.
Watts 00 0C √ X √
30015 8
Phase 2 power.
Watts 00 0E √ X √
30017 9
Phase 3 power.
Watts 00 10 √ X X
30019 10
Phase 1 volt amps.
VA 00 12 √ X √
30021 11
Phase 2 volt amps.
VA 00 14 √ X X
30023 12
Phase 3 volt amps.
VA 00 16 √ X X
30025 13
Phase 1 Reactive Power
VAr 00 18 √ X √
30027 14
Phase 2 Reactive Power
VAr 00 1A √ X X
30029 15
Phase 3 Reactive Power
VAr 00 1C √ X X
30031 16
Phase 1 power factor (1).
None 00 1E √ X √
