socomec MASTERYS BC 80 User Manual

36
MASTERYS BC 60-80 kVA - Ref.: IOMMASBCXX06-EN 06
1. 360 V with Pout = 90% Pn.
2. Initial Condition Pout ≤ 80% Pn
3. @ Battery Fully Discharged. Call SOCOMEC support service.
4. @ Battery Fully Charged. Call SOCOMEC support service.
Models 60 80
Input/Output phases 3/3 3/3
Electrical specifications - Input
Mains voltage Vin 3Ph+N 400 V -10% +20% (up to -40% @50% of nominal load)
Input frequency Hz 50-60 ±10%
Input power factor > 0.99
THDI < 3%
Electrical specifications - External battery
Battery voltage range V bat from from ±198
3
up to ±360
4
Electrical specifications - Output
Output voltage
(three phase + neutral)
V 400 V three phase (selectable 360/380/400/415 V) ±1%
1
Frequency Hz 50-60 Hz ±2% (from 1% to 8% if generator is used)
Automatic bypass
nominal output voltage ±15%
(from 10% to 20% selectable if generator is used)
Nominal power kW 54 72
Overload
(@ 25 °C; Vin >
380; Vbat > 216)
2
• 10 minutes
• 1 minute
kW
67,5
81
90
108
Crest factor ≥ 2.7
Voltage distortion 1% with linear load
Environment
Operating temperature °C 0÷35 (15÷25 recommended for longer battery life)
Storage temperature °C -5÷45
Relative humidity % 0÷95% condensation-free
Max. altitude m 1.000 without derating; 3.000 max
Acoustic noise dBA < 62 < 62
Required cooling capacity m
3
/h 1330 1330
Dissipated power max W 5341 7121
Dissipated power max BTU/h 18,234 24,312
Standards
Safety EN 62040-1/A1, EN 60950-1
Type and performance EN 62040-3 (VFI-SS-111)
EMC EN 62040-2 (Category C3)
Product certifi cation CE - TÜV-SÜD
Protection level IP20, IP21 on request
Mechanical characteristics with standard batteries
Dimensions (LxPxH) mm 444 x 795 x 1400 444 x 795 x 1400
Weight kg 200
1
210
1
10. TECHNICAL SPECIFICATIONS
