MASTERYS BC 60-80 kVA - Ref.: IOMMASBCXX06-EN 06
5. MIMIC PANEL
5.1.8. Service menu
This is used to change the configuration parameters, insert the warranty activation code and display the service code.
5.1.9. UPS SETTINGS menu
This is used to change the configuration parameters. Access is via the password MAST which is keyed in by using the and
keys and ENTER to go on to the next letter.
UPS SETTINGS menu
Parameter Description Allowed values
SET LANGUAGE Sets the required language English, Français, Italiano,
Deutsch, Español
SET OUTPUT VOLTAGE Sets the required output voltage value 208/220/230/240 V
SET OUTPUT FREQUENCY Sets the required output frequency value 50/60 Hz
SET MODE CONVERTER Sets whether or not the UPS has to operate as a
frequency converter
WARNING! Set only on UPS with mains power
(MAINS) and auxiliary mains (AUX MAINS) sepa-
rated and with the auxiliary mains (AUX MAINS)
disconnected! Do not set on UPS with common
mains lines as it could damage the load!
YES/NO
SET MODE AUTORESTART Sets whether or not the UPS has to restart automatically
after shutdown due to minimum battery
YES/NO
SET BATTERY AVAILABLE Set if battery is present YES/NO
if YES:
- SET BATTERY TYPE Selects the type of batteries used Sealed
- SET BATTERY CAPACITY Sets the battery capacity in Ah 9.5 – 1000 Ah
- SET CHARGER TYPE Selects the type of recharge required Auto, Float, int.
- SET BATTERY ELEMENTS Set the number of battery elements 120-132
- SET BATT_TEST PERIOD Sets the frequency rate of the battery test in days 0, 30, 60, 90, 120,150,180 (zero
do not perform the test) in days
SET BACKFEED Sets the type of backfeed protection Disable,
2.ByPass-Input alone,
3.ByPass-Input common
SERIAL LINK Inserts the serial communication parameters:
- Serial Link Baud Rate
- Serial Link Parity
- Serial Link Bit Number
- Serial Link Stop Bits
When the data is confi rmed, the serial connection automatically
changes the confi guration without having to switch o the UPS.
1200/2400/4800/9600/14.4
odd/even/none
8-9
0-1
JBUS SETTING SLAVE NR. Sets the mimic panel jbus node
When the data is confi rmed, the serial connection au-
tomatically changes the confi guration without having to
switch o the UPS.
1/32
DATE SETUP Sets the date DD/MM/YY
TIME SETUP Sets the time HH:MM
SYN EXT CMDS ENABLED Enables/Disables the mimic panel extended commands YES/NO
REMOTE CMDS ENABLED
Enables the transmission of commands from external systems YES/NO
SET BUZZER ENABLED Enables/Disables the buzzer YES/NO
