23
ENGLISH
MASTERYS BC 60-80 kVA - Ref.: IOMMASBCXX06-EN 06
5. MIMIC PANEL
5.1.5. Measurements menu
This menu is used to display all measurements relating to UPS input, output, and the battery. For models with single phase input or output,
the voltage and current displays are adjusted automatically.
MEASUREMENTS menu
Type of measurements Value Value Value Note
OUTPUT VOLTAGE ___ V ___ V ___ V Output voltage
OUTPUT LOAD __ % __ % __ % Output load percentage
OUT ACTIVE PWR __._ kW Output active power
OUTPUT FREQNCY __._ Hz Output frequency
AUX VOLTAGE ___ V ___ V ___ V Auxiliary mains voltage
AUX FREQUENCY __._ Hz Auxiliary mains frequency
INPUT VOLTAGE ___ V ___ V ___ V Input mains voltage
INPUT FREQUENCY __._ Hz Input mains frequency
BATTERY VOLTAGE B+___ V B+___ V Battery voltage
CAPACITY __ % Battery capacity percentage during charging
BACKUP INFO T___MIN Backup time during battery discharge
INTERNAL TEMP. __ °C Internal temperature
5.1.6. Commands menu
This is used to send immediate commands for start-up/shutdown/reset alarms to the UPS and to select the operating mode.
Commands can also be sent for diagnostic purposes by means of the extended commands menu (if enabled in the configurations
menu). The command is activated by selecting it with the and keys, press ENTER, confirm YES or NO, then press ENTER.
IMMEDIATE COMMANDS menu
Command Description
START PROCEDURE UPS start-up command
STOP PROCEDURE UPS shutdown command
HIGH EFF. MODE High e ciency mode: activates the energy saving feature
NORMAL MODE Activates normal double conversion operation
ALARMS RESET Resets all the alarms
LEDS TEST Performs test on mimic panel LEDs
EXTENDED COMMANDS menu
Command Description
BATTERY TEST Activates the battery test to check battery e ciency
BATT.COMMISSION Activates forming charging for the battery
CHECK-UP DISAB. Disables the regular maintenance message
5.1.7. Parameters menu
Displays the UPS parameters set.
UPS CURRENT DATA menu
Message Description
MASTERYS 3/3 30 KVA
SN. 0000000000
Displays the size, input and output phase confi guration and UPS serial number
UC FW. REVISION
RV 000 CKS: 0000
Identifi es the microprocessor software release
DSP FW. REVISION
RV 000 CKS: 0000
Identifi es DSP software release
