NETYS RT 5 - 7 - 9 - 11 kVA - 551570A - SOCOMEC
21
EN
3.3. LCD Display
BYPS
231 V
PS
3.3.1. Icon/ Display Deî›°nition
No. Icon/ Display Description
1 Indicates that power supply is OK.
2
Indicates that the power share output is ON.
Indicates that the power share output is OFF.
3
Indicates the battery capacity level.
Indicates that the battery is abnormal and
needs replacement. If the battery is abnormal,
the battery capacity icon ( ) will be empty.
4
Indicates the load level (%).
5
When the UPS runs normally, the display will
show the input voltage.
6
When the UPS has abnormalities or is in fault
condition, the display will show an error code
and its corresponding fault or warning message.
7 Indicates that the buzzer is muted.
8
Indicates that the output is overloaded
To Next Page
