No. Item Functions
3
Dry Contacts
1. Output dry contacts: These receive the
UPS’s event information to indicate the UPS
status or internal messages.
2. Input dry contacts: Lets the UPS receive
external control signals.
3. For more information, please refer to
Chapter 5: Communication Interfaces.
4
REPO Port
When emergency events occur, it can shut
down the UPS safely and immediately.
Please refer to Chapter 4: REPO Port for
details.
5
RS-485 Port
Connects to a computer so you can monitor
the UPS status or let the UPS communicate
with lithium ion batteries.
6
RS-232 Port
Connects to a computer so you can moni-
tor the state of the UPS, congure the UPS
parameters and upgrade the UPS rmware.
Please refer to Chapter 5.6 RS-232 Port and
USB for more information.
The USB port and the RS-232 port must
not be used simultaneously. The USB
port has the higher priority.
7
(USB Port)
Connects to a computer so you can moni-
tor the state of the UPS, congure the UPS
parameters.
Please refer to Chapter 5.6 RS-232 Port and
USB for more information.
The USB port and the RS-232 port must
not be used simultaneously. The USB
port has the higher priority.
8
Input Breaker
Controls the UPS’s input switch and for
safety protection.
9
External Batt.
Connector
Connects to the external battery pack
(optional).
5K: 192V DC 29A
7K: 192V DC 35A
9K: 240V DC 37A
11K: 240V DC 46A
