socomec NRT3-U5000 & NRT3-U5000C & NRT3-U7000 & NRT3-U7000C & NRT3-U7000CLA User Manual

NETYS RT 5 - 7 - 9 - 11 kVA - 551570A - SOCOMEC
75
EN
10.2.5. How to Install the Manual Bypass on the Rack
The No.
1
~
11
shown in Figure 10-4 ~ Figure 10-13 represent the standard
accessories mentioned in §10.1.7 Package List.
1
Use the four M4 screws (
8
) to x the two MBP Ears (
8
) on the left and right
sides of the MBP (please see Figure 4).
2
Fix the four M5 cage nuts (
8
) on the two sides of the rack (please see Figure 4).
3
Use the four M5 screws (
8
) to secure the MBP on the rack’s M5 cage nuts (
8
)
(please see Figure 10-7).
WARNING:
OPENING THIS C
INVERTER SHUTDOWN.
ONLY AUTHORIZED SERVICE PERSONNEL
CAN OPEN AND OPERATE IT.
T
O
U
P
S
P
A
R
A
L
L
E
L
T
O
U
P
S
P
A
R
A
L
L
E
L
L
N
L
N
U
P
S
O
U
T
P
U
T
U
P
S
I
N
P
U
T
OUTPUT BREAKER-1
OUTPUT BREAKER-2
OUTPUT SOCKET-2
20A MAX. PER OUTLET
OUTPUT SOCKET-1
10A MAX. PER OUTLET
I
N
P
U
T
O
U
T
P
U
T
M5 Cage Nut × 4 ( )
8
MBP Ear × 2 ( )
8
M5 Screw × 4 ( )
8
MBB
M4 Screw × 4 ( )
8
OUTPUT
L
N
L
AC INPUT
N
(Figure 10-7)
10.2.6. Wiring
Before wiring:
1. Follow §10.1.6 Important Safety Instructions.
2. When connecting the Manual Bypass to the mains and the loads, you
must install protective devices. The protective devices must be approved
components that meet safety certications.
3. Ensure that all of the breakers/ switches are in the OFF position before wiring.
4. Please refer to the following table to select appropriate input cables,
output cables and protective devices.
NRT3-OP-MBP:
Rating 5 / 7 kVA 9 / 11 kVA
Input/ Output Cable 6mm
2
(Cu) 10mm
2
(Cu)
Protective Device 50A/ D 80A/ D
NRT3-OP-PMB:
Rating 14 kVA 22 kVA
Input/ Output Cable 16mm
2
(Cu) 35mm
2
(Cu)
Protective Device 80A/ D 125A/ D
