SOFAR 15~24KTLX-G3 User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd.
- 10 -
Function description of inverter box bottom
1 2 3 4 5 7
8
6
1. DC Switch
5. Breather valve
2. DC negative poles connecters
6. COM Port (for RS485 communication)
3. DC positive poles connecters
7. AC output
4. USB Port (for WIFI or Ethernet
communication)
8. Fans
Figure 2-6 Bottom view of the SOFAR 15~24KTLX-G3
Labels on the equipment
Note: label must NOT be hidden with objects and extraneous parts (rags, boxes, equipment,
etc.,); they must be cleaned regularly and kept visible at all times.
Figure 2-7 Product label
