Sofar 100KTLX-G4 User Manual

Installing the bracket on a standInstalling the bracket on a stand
1. 1. Use wall mount bracket, ensure the pole position are in same level by using level
rule and mark the holes.
2. 2. Drilling holes by using a Hammer Drill.
3. 3. UseM10screwandM10󰘱atwashertosecurethewallbracket.
M10x50screwandM10󰘱atwasherneedself-preparation.
26/78 SOFAR 100...125KTLX-G4
Installation

Sofar 100KTLX-G4 Specifications

General

Brand	Sofar
Model	100KTLX-G4
Category	Inverter
Language	English
