11 11 Technical DataTechnical Data
DatasheetDatasheet
SOFARSOFAR
100KTLX-G4100KTLX-G4
SOFARSOFAR
110KTLX-G4110KTLX-G4
SOFARSOFAR
125KTLX-G4125KTLX-G4
SOFARSOFAR
125KTLX-G4-A125KTLX-G4-A
Input DCInput DC
Max. input voltage 1100 V
Rated input voltage 625 V
Start-up voltage 200 V
MPPT operating
voltage range
180 – 1000 V
Number of MPP
trackers
10
Number of DC inputs 20
Max. input MPPT
current
10 – 40 A
Max. input short
circuit current
10 – 50 A
Output (AC)Output (AC)
Rated output power 100 kW 100 kW 110 kW 125 kW
AC output power
100kVA@45℃
90kVA@50℃
110kVA@45℃
100kVA@50℃
125kVA@45℃
110kVA@50℃
125kVA@45℃
110kVA@50℃
Max. Output current
152 A @ 380 V
145 A @ 400 V
139.2 A @ 415 V
167.2 A @ 380 V
159.5 A @ 400 V
153.1 A @ 415 V
190 A @ 380 V
181.2 A @ 400 V
174 A @ 415 V
190 A @ 380 V
181.2 A @ 400 V
174 A @ 415 V
Rated grid voltage 3/N/PE, 380 V / 400 V / 415 V
Grid voltage range 310 – 480 V
Rated frequency 50/60 Hz
Grid frequency range 45 – 55Hz / 55 – 65 Hz
Active power adjust-
able range
0–100%
THDi <1%(@100%P)
Power factor 1 default (+/-0.8 adjustable)
Initial short-circuit AC
current
756.7 A-peak
E󰘲ciencyE󰘲ciency
Installation and User Manual 69/78
