ELECTRICAL CONNECTIONS
SOFAR 1100...3300TL-G3 53
The wiring methods for RS485 and the current sensor (CT) are
identical:
Communication function
RS485
CT
Cable cross-section
0.5 ... 1.5mm²
0.5 ... 1.5mm²
Outer diameter
2.5 ... 6 mm
2.5 ... 6 mm
1. Remove the waterproof cover of the communication interface
using a screwdriver;
2. Release the waterproof cable gland and remove the plug of the
waterproof connector;
