ELECTRICAL CONNECTIONS
54 SOFAR 1100...3300TL-G3
3. Select a suitable cable and strip it approx. 6 mm. Guide the cable
through the cable gland and the waterproof cover, connect the
wires and tighten the screws of the terminal using a slot head
screwdriver.
4. Engage the terminal in accordance with the imprinted label, and
then tighten the screws to fasten the waterproof cover. Turn the
cable gland clockwise in order to ensure secure fastening.
