The pin definitions of the logic interface and the switching
connections are as follows:
The function of the logic interface must be set on the LCD display;
please observe the operating steps in section 6.3.
Logic interface pins are defined in accordance with various standard
specifications.
Logic interface for AS/NZS 4777.2:2015
also known as Inverter Demand Response Modes (DRMs)
The inverter recognises all supported Demand Response commands
and initiates the reaction within two seconds.
