ELECTRICAL CONNECTIONS
58 SOFAR 1100...3300TL-G3
Functional description of the terminal
Pin
Name
Inverter
Radio ripple control
receiver
1
L1
Relay 1 input
K1 - output relay 1
5
G
Earth
Relay, earth
The inverter is preconfigured on the following power levels.
Relay status: Closing is 1, opening is 0
L1
Active
power
Power drop rate
Cos (φ)
1
0%
< 5 seconds
1
0
100%
/
1
