4. Electrical Connections
4.1. Outlines of this chapter
This topic describes the SOFAR 7K~10.5KTLM-G3 inverter electrical
connections. Read this part carefully before connecting cables.
NOTE: Before performing electrical connections, ensure that the DC switch is OFF.
Since the stored electrical charge remains in a capacitor after the DC switch is turned OFF.
So it’s necessary to wait for at least 5 minutes for the capacitor to be electrically
discharged.
Installation and maintenance of inverter, must be operated by professional
electrical engineer.
Attention
PV modules generate electric energy when exposed to sunlight and can
create an electrical shock hazard. Therefore, before connecting DC input
power cable, cover PV modules using opaque clot
Danger
For SOFAR 7K~10.5KTLM-G3,open-circuit voltage(Voc) of module
arrays connected in series must be≤550V.
Note
The connected PV modules must have an IEC 61730 Class A ratin
IscPV(absolute maximum)
30A/22.5A/22.5A
Maximum output over current
protection
SOFAR 7KTLM-G3
37A
SOFAR 7.7KTLM-G3
37A
SOFAR 8KTLM-G3
42A
SOFAR 9KTLM-G3
47A
SOFAR10KTLM-G3
48A
SOFAR 10.5KTLM-G3
48A
The decisive voltage class(DVC)
NOTE:The DVC is the voltage of a circuit which occurs continuously between any two
live part in the worst-case rated operating condition when used as intended.
