GCM General Control Module
42
To display card reads in hexadecimal on the LCD panel, set switch 4-8 On. The
data that is displayed is left-justified. There may be some unused bits on the
right side of the display.
The Reset Switch, S5, will cause the GCM computer to reboot. Pressing S5 will
also clear memory, including configured readers, inputs and outputs. As long
as there is a connection to the host, these objects will immediately be
downloaded to the iSTAR Pro memory.
If switch S4-2 is on when S5 is pressed, the unit will be reset to factory default.
This means that all of the connection data, such as the IP address will be cleared
in addition to the memory. In this case the unit will have to be totally
configured again using ICU.exe.
