ACM - Access Control Module(s)
45
LEDs
NOTE
DS1 and DS2 should be on solid. If they are blinking, it indicates that something
(e.g., Reader, I/8, R/8, etc.) is configured in the software but is not seen by the
hardware. This may or not be a hardware failure, depending on the intent of the
technician. (i.e., It is possible to configure hardware before actually installing it.)
If DS1 and DS2 are blinking, it causes some overhead to the iSTAR.
Switches
TABLE 19. ACM Switch Functions
TABLE 18. ACM LEDs
LED Function
DS3
Indicates power to the ACM.
DS1 Indicates Rx on the RS485 half duplex reader bus.
DS2 Indicates Tx on the RS485 half duplex reader bus.
DS4 - DS11 Displays the eight outputs on the ACM.
Switch Function Description
S5 Reset Switch Resets the iSTAR ACM
S2 Enable Wiegand
Ports
Do Not Use
S4 Terminate the RM
RS485 Ports
(STAR1-STAR8)
These switches default to ON and
generally should not be changed. Setting
the switch to OFF places the STARn port
in the middle of the RS485 chain, which
allows the technician to connect two
sections of a reader bus to this point. In
this case, termination must be provided
at the end of each of those connections,
but not at the STARn connector.
See Figure 8 on page 17.
S3 LED and Beep
Control
Do Not Use
