Overview
5
Mounting Instructions,
4 Post IT Rack
Install Rack Rails to both sides of iSTAR Pro Rack enclosure. (Screws
Provided)
Install Rack Rails to Server Rack.
Slide iSTAR Pro into Rack Rails on Server Rack
Attach iSTAR to Server Rack for added Security
Mounting Instructions,
2 Post Telco Rack
The 4U Rack Mount can also be mounted in a 2 Post Telco style rack by using a
2 post conversion kit.
Install Rack Rails to both sides of iSTAR Pro Rack enclosure. (Screws
Provided)
Install 2 post conversion kit
Install rack rails onto metal extensions of the conversion kit
Slide iSTAR Pro onto the rails of the conversion kit
Attach iSTAR to Server Rack for added Security
Network Connection
Connect a CAT-5 or CAT-6 RJ45 cable to J4. Connect a straight through cable
to a Switch or Hub. If unit is connected directly to the server use a crossover
cable.
GCM LED2 indicates the Ethernet link signal and LED1 displays the Receive
Data signal.
