Configuring Intrusion Zone Doors
64
Configuring Intrusion Zone Doors
To add doors to an intrusion zone, select the Doors tab:
Use the Add and Remove buttons to add and remove doors.
iSTAR Door Options
Table 26 shows iSTAR door configuration options. Use the horizontal scroll bar
in the Doors Selected area to display these options.
TABLE 26. iSTAR Door Configuration Options
Option Description
Arm/Disarm
State
Locked - access is granted with valid card
Unlocked - door is open. Access not required.
Secure - door is locked and card access is not allowed. Door must be
changed to locked or unlocked to provide access.
Direction Used by the system to determine if a strike (unlock) action is required:
In - For almost all intrusion zones, the In reader leads into the zone and the
Out reader leads out of the zone.
Out - Configured for atypical intrusion zones. Reverses the reader settings,
so that the In reader leads out of the zone and the Out reader leads in.
Card Control Enables or disables readers in the zone to use card control to arm and
disarm the zone.
Display Blank - sets the LCD display on readers to display time/date (first line) and
a second line that is blank (except for occasional display of mode or control
messages.)
Status - displays time/date (first line) and intrusion zone status (second
line)
