Configuring Status Links
72
Configuring Status Links
Intrusion zones provide options that link status to events (iSTAR). Use these
options to:
Display iSTAR status and respond to violations by linking status to events
(for example, display status using indicator lights and respond to violations
by sounding alarms.)
Status Link Dialog Boxes
To configure event status, select:
Configure>Intrusion Zone>iSTAR Intrusion Zone>Edit/New>Events
(iSTAR)
Status Link Options
The C•CURE 800/8000 provides status links that activate when the zone is:
Disarmed
Armed
Not ready to arm
Violated.
There are specific considerations when using the iSTAR Pro 4U Rack Mount as
an intrusion detection / burglar alarm system, per ANSI/UL 1076
TABLE 29. Specific considerations ANSI/UL 1076
UL 1076 Intrusion Detection / Burglar Alarm Recommendations
Recommended Arm/Disarm Device RM2L-4000 multi-technology reader with keypad
& display, to provide visual indication of
individual zone status to operator
AC Power Source Must use a UL-approved UPS, sized to provide 4
hours of full operation when main AC power is
not present
Local Sounder Recommend to install local horn, activated when
the zone is in alarm
Maximum number of protection inputs per zone 32
Maximum number of non-protection inputs per zone 32
Maximum number of readers per zone 16
