SolarEdge Firefighter Gateway User Manual

Chapter 1: Introducing the SolarEdge Firefighter Gateway
Firefighter Gateway Installation Guide MAN-01-00113-1.2
9
Communication Connectors

Antenna1: Used for optional wireless antenna connection – ZigBee or Wi-Fi (refer to Creating a
Wireless ZigBee Connection on page 40 and Creating a Wi-Fi Connection on page 40)

Antenna2: Currently not installed

RS485-1 and RS485-2: Used for connecting external devices to the gateway (refer Chapter 4:
Connecting the Firefighter Gateway to the SolarEdge Installation on page 18)

RS232: Enables connection of the SolarEdge gateway to an external device using an RS232 interface

Mini-USB: Enables PC/laptop connection for using the SolarEdge configuration tool.

Ethernet: Enables connecting the SolarEdge gateway to the SolarEdge monitoring portal through an
Ethernet switch/router (refer to Creating an Ethernet (LAN) Connection on page 35). The Ethernet
switch/router should be connected to the Internet.
Other Interfaces

Control: Used for connection to an external emergency stop button (refer to Chapter 3: Connecting
Emergency Stop Button or Fire Alarm Control on page 14).

SW1/SW2: RS485-1/2 termination

DC: Used for the power supply input as described in Connecting the Firefighter Gateway to AC on
page 13

Micro SD: Used for field software upgrade

Sensors: Not applicable

LEDs: All LEDs are ON while the SolarEdge gateway is powered up or configured.

SolarEdge Firefighter Gateway Specifications

General

Brand	SolarEdge
Model	Firefighter Gateway
Category	Control Unit
Language	English
