Remote Shutdown
Select Remote Shutdownto set the following:
L 1 P o l a r i t y < N o r m . >
L 2 P o l a r i t y < N o r m . >
S a f e V d c < 1 2 0 V >
C l r A l a r m M o d e < M >
C l e a r A l a r m
L1/L2 Polarity: The lines polarity - Normal (default) or Reverse
Safe Vdc: Threshold value for safe Vdc: When the maximum voltage (of all connected devices)
reaches this threshold, the display will show Safe DC in the main gateway status screen. Select
either:
Safe Vdc. – sets the threshold to the default 120V
Setting the threshold in the range between 30 -120V (default 120V)
Clr Alarm Mode: Enables clearing the alarms of emergency stop. Select either:
Automatic (default) – when releasing the stop button, the system returns to normal opertaion
Manual - when releasing the stop button, clear the alarm manually (select Clear Alarm below)
in order to return the system to normal operation
Clear Alarm: Appears only if Clr Alarm Mode is set to Manual and a stop command has already been
sent. After releasing the stop button, select this option to return to normal operation.
For more information, refer to Chapter 3: Connecting Emergency Stop Button or Fire Alarm Control on
page 14
Display
Select Display to set the following:
L C D O n T i m e < 3 0 >
LCD On Time <30>: The number of seconds that the LCD backlight is ON after the LCD button is
pressed. Set to 0 if you want the LCD to be lit at all times.
Maintenance
Select Maintenance to set the following options:
D a t e a n d T i m e
F a c t o r y R e s e t
S W U p g r a d e S D C a r d
Date and Time: Set the internal real-time clock. If connected to the SolarEdge monitoring portal, the
date and time are set automatically and only time zone should be set.
Factory Reset: Perform a general reset to the gateway default settings.
SW Upgrade SD Card: Perform a software upgrade using an SD card.
To Next Page
