Chapter 6: LCD – Status Screens and Setup Options
Firefighter Gateway Installation Guide MAN-01-00113-1.2
The following shows a hierarchical tree of the menu options:
L a n g u a g e < e n g >
C o m m u n i c a t i o n
R e m o t e S h u t d o w n
D i s p l a y
M a i n t e n a n c e
I n f o r m a t i o n
Language:
E n g l i s h
G e r m a n
S p a n i s h
F r e n c h
I t a l i a n
Communication
1
:
S e r v e r < L A N >
L A N C o n f
R S 4 8 5 – 1 C o n f < M >
R S 4 8 5 – 2 C o n f < >
Z i g B e e C o n f < >
Wi- F i C o n f < >
R S 2 3 2 C o n f
Remote Shutdown
L1 P o l a r i t y < N o r m . >
L 2 P o l a r i t y < N o r m . >
S a f e V d c < 1 2 0 V >
C l r A l a r m M o d e < A >
Display:
L C D O n T i m e < 3 0 >
Maintenance:
D a t e a n d T i m e
F a c t o r y R e s e t
S W U p g r a d e - S D C a r d
Information:
V e r s i o n s
E r r o r L o g
W a r n i n g l o g
This section describes how to use the LCD menus for configuring the SolarEdge gateway.
1
If Wi-Fi is connected, the ZigBee item is not displayed, and vice versa.
