5
L30US-IB80, L30US-IB00, L40US UPS
• Check if the battery is inadvertently grounded. If it is, remove the source
from ground. Contact with any part of a grounded battery can result in
electrical shock. The likelihood of such shock can be reduced if such grounds
are removed during installation and maintenance.
These UPS units are extremely heavy. Caution should be taken in moving and
positioning this equipment. These safety instructions are important and should
be precisely followed during installation, operation, and maintenance of the
UPS and batteries.
CAUTION!
The unit carries hazardous voltage. When the UPS is on, its outlets may carry
hazardous voltage even when not plugged into the wall outlet, because the
battery may continue to supply power.
Care should be taken to install the UPS in an indoor environment which is
under temperature and humidity control, free from electrically conductive
particles, with reduced risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the
equipment is placed in a position near the easily accessible outlet.
Except for replacing the batteries, all servicing on this equipment must be
carried out by qualified service personnel.
Before conducting any maintenance, repair, or shipment, first ensure that all the
UPS equipment is completely turned off and disconnected.
For additional safety instructions, see Safety section of the Service Manual.
Table 1 Batteries Quantity
Model Rating SolarEdge P/N Description
L30US-IB80 30 kVA L30IBUS-L6G4V09001 L30US 3PH 4W UPS 208V 30KVA/30KW IB80
L30US-IB00 30 kVA L30IBUS-L6G0V09001 L30US 3PH 4W UPS 208V 30KVA/30KW IB00
L40US 40 kVA L40US-L6G0VNN001 L40US 3PH 4W UPS 208V 40KVA/40KW IB00
