L30US-IB80, L30US-IB00, L40US UPS
1.
Preface
1.1. Standards and Conventions
This User Guide contains diagrams that include images of the display screen of the UPS.
Unless otherwise indicated, the readings shown in the screen images are only illustrative and
are not intended to match the readings on a specific system in any particular environment.
Operation and control of the L Family UPSes are performed through a touch-sensitive LCD
display screen. In this manual, when explaining how to navigate the control software via the
touch-sensitive screen, the terms "tap", "press", "choose", and "select" may be used
interchangeably to indicate selection of a screen option.
Most of the electrical abbreviations in this document are according to IEEE 280 Standard
Letter Symbols for Quantities Used in Electrical Science and Electrical Engineering.
1.2. Safety Symbols Information
The following safety symbols are used in this document. Familiarize yourself with the
symbols and their meaning before installing or operating the system.
NOTE!
Denotes additional information about the current subject.
CAUTION!
Denotes a caution. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in damage to the unit or load. Do not
proceed beyond a caution note until the indicated conditions are fully
understood and met.
WARNING!
Denotes a warning. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in injury or loss of life. Do not proceed
beyond a warning note until the indicated conditions are fully understood and
met.
