56
L30US-IB80, L30US-IB00, L40US UPS
UPS Faults
Beeps/2s or
Beeps/1s
Yes On On Off Off
4.4.2. Faults and alarms reports
Table 7 Fault Information
No
Fault
Cord
UPS Alarm Warning Buzzer LED
1
002 REC Over Temperature Twice per second Fault LED lit
2
003 REC par. cable Fault Twice per second Fault LED lit
3
004 REC Over Current Beeps continuously Fault LED lit
4
005 REC Power Fault Beeps continuously Fault LED lit
5
007 Input SCR Fault Beeps continuously Fault LED lit
6
00A Battery SCR Fault Beeps continuously Fault LED lit
7
00C Charge SCR Fault Beeps continuously Fault LED lit
8
00E Fan Fault Beeps continuously Fault LED lit
9
011 Fan Power fault Beeps continuously Fault LED lit
10
012 Charger Over Temp. Beeps continuously Fault LED lit
11
013 Soft Start Failed Beeps continuously Fault LED lit
12
014 BAT Charger Fault Beeps continuously Fault LED lit
13
016 REC Comm. Fault Once per 2 seconds Fault LED blinking
14
019 REC Initializes Fault Beeps continuously Fault LED lit
15
01D
Unit insert fault
Once per 2 seconds Fault LED lit
16
063 Once per 2 seconds Fault LED lit
17
01E Rectifier Fault Beeps continuously Fault LED lit
18
041 Inverter Fault Beeps continuously Fault LED lit
