L30US-IB80, L30US-IB00, L40US UPS

Appendix 1: Specifications

Table 10 Specifications

Model L30US-

IB80

L30US-IB00 L40US

General

Capacity (VA/Watts) 30K / 30K 40K / 40K

Input and output type 4W/4W+PE

Design rating (power module

technical rating)

30KW power module x1

20KW power

module x2

Efficiency

(with linear

load)

Normal mode

Up to 94%

ECO mode Up to 98%

Short circuit capacity Icc (KAIC)

Parallel system (integrated

parallel / Static Switch Cubicle)

Up to 2

Configuration

s or

architecture

Standalone Yes

Parallel Yes

Frequency

converter

Yes

Bus Synchronization

without external box

Input

THDI (100% Load) <3%

PF (100% R Load) >0.99

Frequency tolerance 40-70Hz
