Page #103 background image
Three Phase Inverters with Synergy Technology PN: SExxK-xxxxIxxxx
102 Appendix F: Immunity Standards
Appendix F: Immunity Standards
The information in this appendix complies with the IEEE 1547-2018 standard. The IEEE
1547-2018 standard, establishes criteria and requirements for interconnection of
distributed energy resources (DER) with electric power systems (EPS) and associated
interfaces.
Test type Test method Test Level
Radiated Immunity IEEE C37.90.2 20 V/m
EFT IEEE C37.90.1, C62.45, C62.41.2
+3 kV
+4 kV
Surge IEEE C62.45, C62.41.2, UL 1741
+3 kV
+6 kV
Oscillatory Test IEEE C37.90.1 2.5 kV

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SolarEdge SE100K and is the answer not in the manual?

SolarEdge SE100K Specifications

General IconGeneral
Max. Efficiency98.8%
Transformer-lessYes
Protection RatingIP65
Frequency50/60 Hz
AC Output Power100 kW
Rated AC Power100, 000 W
Maximum DC Power135000 W
AC Voltage400 V
Max. Input Voltage1000Vdc
Operating Temperature Range-25°C to 60°C
