Chapter 6: Setting Up Communication to the
Monitoring Platform
The inverter sends the following information to the monitoring platform:
Power optimizer information received via the DC power lines (the PV output circuit)
Inverter information
Information of any other connected devices
This chapter describes how to set up communication between:
The inverter and the monitoring platform through the Internet (wired/ wireless), or
through a cellular connection
Multiple inverters for a master/slave configuration
Communication setup is not required for power harvesting, however it is needed for
using the monitoring platform.
CAUTION!
When connecting the communication cables, make sure that the ON/OFF/P
switch at the bottom of the inverter is turned OFF, and the AC is turned OFF.
When configuring the communication parameters, make sure that the
ON/OFF/P switch (and the switch of the DC Safety Unit if applicable) is OFF,
and the AC is turned ON.
Communication Options
The following types of communication can be used to transfer the monitored
information from the inverter to the monitoring platform.
Only communication products offered by SolarEdge are supported.
Ethernet
Ethernet is used for a LAN connection. For connection instructions refer to
Creating an
Ethernet (LAN) Connection
on page 51 .
RS485
RS485 is used for the connection of multiple SolarEdge devices on the same bus in a
master-slave configuration. RS485 can also be used as an interface to external devices,
such as meters and third party data loggers.
Chapter 6: Setting Up Communication to the Monitoring Platform 47
Single Phase Inverter with HD-Wave Technology Installation MAN-01-00540-1.0
For connection instructions refer to
Creating an RS485 Bus Connection
on page 54.
