SE8000H SE10000H Units
OUTPUT
Rated AC Power Output 8000 10000 VA
Maximum AC Power Output 8000 10000 VA
AC Output Voltage (Nominal) 220 / 230 Vac
AC Output Voltage Range 184 - 264.5 Vac
AC Frequency (Nominal) 50 / 60 ± 5 Hz
Maximum Continuous Output Current 36.5 45.5 A
Max. continuous overcurrent protection 36.5 45.5 A
Residual Current Detector / Residual Current Step Detector 300 / 30 mA
Inrush current AC (Peak/Duration) 3.45 / 20 Aac(rms) / ms
Max. output fault current 80 A
Power factor range 1 (adjustable from -0.8 to +0.8)
Total harmonic distortion < 3 %
Protective class Class I
Utility Monitoring, Islanding Protection, Country Configurable Thresholds Yes
Overvoltage category
III
SolarEdge-Single Phase Inverters with HD-Wave Technology Specifications (Europe & APAC) MAN-01-00553-1.0
Technical Specifications - Single Phase Inverters with HD-Wave Technology
(Europe & APAC)
1
