SE8000H SE10000H Units
INSTALLATION SPECIFICATIONS
AC Output- Cable Gland diameter 9 - 16 mm
AC Supported Wire Cross Section 1 - 13 mm
2
DC Input
1
3 x MC4 pair
Dimensions (HxWxD) 360 x 370 x 185 mm
Noise < 50 dBA
Weight 16.5 kg
Cooling Natural Convection
Operating Temperature Range
2
-40 to +60 °C
Protection Rating IP65 - Outdoor and Indoor
Recommended circuit breaker/ fuse size to use at the connection point of the SolarEdge inverter to the grid:
Inverter Maximum Output Current (A) Minimum Fuse Rating (A) Maximum fuse rating (A)
SE8000H 36.5 50 80
SE10000H 45.5 63 80
1
Connection of additional strings in parallel to a single input is allowed as long as the cumulative current does not exceed 45A.
2
For power de-rating information refer to: https://www.solaredge.com/sites/default/files/se-temperature-derating-note.pdf
SolarEdge-Single Phase Inverters with HD-Wave Technology Specifications (Europe & APAC) MAN-01-00553-1.0
3
