washers) for attaching:
the Primary and Secondary Unit(s) mounting brackets to the mounting
surface
the power optimizers to the racking (not required for smart modules)
MC4 crimper
4xM8 ring terminals and suitable crimper
Wire cutters
Wire strippers
Voltmeter
For installing the communication options, you may also need the following:
For Ethernet:
CAT5/6 twisted pair Ethernet cable with RJ45 connector
If using a CAT5/6 cable spool: RJ45 plug and RJ45 crimper
For RS485:
Four- or six-wire shielded twisted pair cable.
Watchmaker precision screwdriver set
For secondary grounding:
Ring terminal crimper for the AC wire
Ring terminal
Serrated washer
Grounding screw
Two washers
Chapter 1: Introducing the SolarEdge Power Harvesting System 13
Three Phase Inverter with Synergy Technology Installation MAN-01-00402-1.2
