Step 1: Mounting the Power Optimizers
For each of the power optimizers
(1)
:
1. Determine the power optimizer mounting location and use the
power optimizer mounting brackets to attach the power optimizer to
the support structure . It is recommended to mount the power
optimizer in a location protected from direct sunlight. For frame-
mounted power optimizers follow the instructions supplied with the
optimizers, or refer to https://www.solaredge.com/sites/default/files/installing_frame_
mounted_power_optimizers.pdf.
2.
If required, mark the mounting hole locations and drill the hole.
CAUTION!
Drilling vibrations may damage the power optimizer and will void the
warranty. Use a torque wrench or an electric drill with adjustable clutch
that meets the mounting torque requirements.
Do not
use impact drivers
for mounting the power optimizer.
Do not
drill through the power optimizer or through the mounting holes.
3.
Attach each power optimizer to the rack using M6 (1/4'') stainless steel bolts, nuts
and washers or other appropriate mounting hardware. Apply torque of 9-10 N*m /
6.5-7 lb*ft.
4. Verify that each power optimizer is securely attached to the module support
structure.
5. Record power optimizer serial numbers and locations, as described in
Reporting
and Monitoring Installation Data
on page 58.
Step 2: Connecting a PV Module to a Power
Optimiser
NOTE
Images are for illustration purposes only. Refer to the label on the product to
identify the plus and minus input and output connectors.
(1)
Not applicable to smart modules.
Chapter 2: Installing the Power Optimizers 17
