Technical Specifications - Smart EV Charger
(North America)
Level 2 EVSE, 40A (9.6kW), Wi-Fi enabled
EV CHARGER SPECIFICATIONS
Charging Mode AC Level 2 
Rated AC Power Output 9.6 kW
Maximum Continuous
Output Current @240
40
(1)
Vac
Nominal AC Output
Voltage
240
(2)
Vac
Nominal AC Frequency 60 Hz
Ground Fault Detection
Threshold
5 mA
Supported Communication
Interfaces
Wi-Fi (built-in antenna included)
(3)
, Ethernet,
RS485 and Cellular (optional)
(4)

FEATURES SUPPORTED WITH INTEGRATED SOLAREDGE INVERTER
Smart Energy Management
Controlled excess solar charging
(5)
and solar
boost mode

ADDITIONAL FEATURES
EV Charger Status LEDs,
Fault Indicator
Yes 
EV Charger Unplugging
Detection
Yes, current termination according to SAE
J1772 EV Charger

EV Charger Ground
Connection Monitoring
Yes, continuous 
EV Charger Configuration
Installer commissioning via SetApp.
Homeowner configuration controls and
monitoring via mySolarEdge app

(1)
Can also be configured to 16A, 24A and 32A.
(2)
Connected to L1, L2, G; No need for neutral.
(3)
To extend Wi-Fi communication, use optional Wi-Fi antenna. For antenna specification refer to se-wifi-
zigbee-wireless-antenna-datasheet-na.pdf
(4)
Optional cellular kit can be ordered.
(5)
When Smart EV Charger is connected to inverter, Import/Export meter is required for controlled Excess
Solar charging
