76
No. Quantity Description
3 1 Mounting rail
4 2 Plastic dowels 8 x 40 (for xing in brickwork)
5 2 Washers M6 x 18 INOX (for the installation of the inverter)
6 2 External hexagon wood screws 6 x 50 INOX (for the installation of the
inverter)
7 2 Phillips head sheet metal screws 4.8 x 13 (for locking the inverter on the
mounting rail)
8 3 Locking pins (for plugging unused holes in multiple cable connectors)
9 4 Locking clips (for DC plugs)
10 1 Toothed lock washer M5
(for connection of 2nd protective
conductor)
11 1 Cable lug M5 x 10mm
2
12 1 Washer M5
13 1 Spring lock washer M5
14 1 Phillips head screw M5 x 12
4.3 Selecting the installation location
DANGER!
Fatal fire or explosion hazard!
The inverter is an electrical device with heat generation and the possibility of
sparking.
Install the inverter in an environment that is free of ammable gases and
uids.
Never install the inverter near combustible materials. The installation
base must be non-combustible.
Follow the local re safety regulations.
The ambient conditions are specied in the specications, see Section 11.
Location and installation conditions
Select a dry location protected from water and snow.
Install the inverter in an easily accessible location, so that maintenance work can be
carried out easily.
Do not expose the inverter to direct sunlight.
Never install one inverter above another (this would reduce the cooling effect; see
Section „Temperature dependent output reduction“; page 122).
