SolarMax 4200S - Page 56

56
Parameter (FW.Rel.6.1) Unit Germany Spain
<= 3.68 kVA
> 3.68 –
<= 13.8kVA
> 13.8 –
<= 30kVA
> 30kVA
VDE
0126-1-1
- Vac MC min V 196 196 196 161 184 196
- f MC max Hz 50.05 50.05 50.05 54.5 50.2 50.5
- f MC min Hz 47.5 47.5 47.5 45.5 47.5 48
- t MC monitoring s60 60 60 0 30 180
Island Detection On/Off On On On On On On
Pac progression %/min10101010 OffOff
P(f)-Mode 2/3/Off2222 2Off
- f start Hz 50.2 50.2 50.2 50.2 50.2 50.2
- Reduction %/Hz 40 40 40 40 40 40
- Re-increase %/min10101010 1010
Q-Mode Off
cosφ(Pac) cosφ(Pac) cosφ(Pac)
Off Off
- Vac Lock On/Off Off Off Off Off Off Off
- Vac Lock-In V 253 253 253 253 253 253
- Vac Lock-Out V 207 207 207 207 207 207
S max SM2000S VA 1980 1980 1980 1980 1980 1980
S max SM3000S VA 2750 2750 2750 2750 2750 2750
S max SM4200S VA - 4180 4180 4180 4180 4180
S max SM6000S VA - 4600 4600 4600 5060 5060
Pac max SM2000S W 1980 1980 1980 1980 1980 1980
Pac max SM3000S W 2750 2750 2750 2750 2750 2750
Pac max SM4200S W - 4180 4180 4180 4180 4180
Pac max SM6000S W - 4600 4600 4600 5060 5060
Iac max SM2000S A12121212 1212
Iac max SM3000S A12121212 1212
Iac max SM4200S A - 19 19 19 19 19
Iac max SM6000S A - 22 22 22 22 22
Parameter Unit Italy France Belgium Czech
Republic
DK 5940
CEI 0-21:
<=3kW
CEI 0-21: >
3kW – 6kW
Vac min 1 V 184 196 196 184 184 207
t Vac min 1 ms 200 400 400 200 120 500
Vac max 1 V 276 264 264 264 264 253
t Vac max 1 ms 100 200 200 200 120 500
Vac min 2 V Off Off Off Off Off 184
t Vac min 2 ms00000100
Vac max 2 V Off Off Off Off Off 276
t Vac max 2 ms00000100
Vac 10min max V Off 253 253 253 253 Off
f min 1 Hz 49 47.5 47.5 47.5 47.5 49.8
t f min 1 ms 100 100 100 200 120 500
f max 1 Hz 51 51.5 51.5 50.2 51.5 50.2
t f max 1 ms 100 100 100 200 120 500
f min 2 Hz Off 49.5 49.5 Off Off 49.5
t f min 2 ms 0 100 100 0 0 100
f max 2 Hz Off 50.5 50.5 Off Off Off
t f max 2 ms 0 100 100 0 0 0
df/dt max Hz/s Off Off Off Off Off Off
Ierr max mA 300 300 300 300 300 300
Iac mean max mA
0.5% of Iac max 0.5% of Iac max 0.5% of Iac max
1000
1% of Iac max
1000
