Function / arameter Description Unit / status
SPILFM3-DLYMAX Tripping time s
Inverter start-up
Function / parameter Description Unit / status
PVGIT Checking the insulation resistance of the PV
generator to ground
-
PVGIT-ENA PVGIT function status Disabled/enabled
PVGIT-THR Minimum permissible insulation resistance Ω
RCMUT Checking the integrated fault current monitoring -
RCMUT-ENA RCMUT function status Disabled/enabled
IST Checking the grid relay
IST-ENA IST function status Disabled/enabled
GPT Checking the grid parameters -
GPT-ENA GPT function status Disabled/enabled
GPTVMIN-THR Minimum permissible mains voltage V
GPTVMA X-THR Maximum permissible mains voltage V
GPTFMIN-THR Minimum permissible mains frequency Hz
GPTFMAX-THR Maximum permissible mains frequency Hz
GPT-MOT Checking duration s
Grid operation
Function / parameter Description Unit / status
GVMMIN1 Checking the minimum permissible mains voltage
(limit 1)
-
GVMMIN1-ENA GVMMIN1 function status Disabled/enabled
GVMMIN1-THR Limit value V
GVMMIN1-DLY Tripping time s
GVMMAX1 Checking the maximum permissible mains voltage
(limit 1)
-
GVMMAX1-ENA GVMMAX1 function status Disabled/enabled
GVMMA X1-THR Limit value V
GVMMAX1-DLY Tripping time s
GVMMIN2 Checking the minimum permissible mains voltage
(limit 2)
-
GVMMIN2-ENA GVMMIN2 function status Disabled/enabled
GVMMIN2-THR Limit value V
GVMMIN2-DLY Tripping time s
GVMMAX2 Checking the maximum permissible mains voltage
(limit 2)
-
