SolarMax 5000P - Page 38

100
Reactive power
Function / parameter Description Unit / status
QMO-AM Reactive power control 0=OFF
QMCQ Reactive power mode constant "Q" -
QMCQ-QSV Reactive power value % of Pac nom
[OEX/UEX]
QMCQ-VLE Status of the voltage-dependent reactive power
control hysteresis for QMCQ
Disabled/enabled
QMCQ-VLIH Upper limit value of the mains voltage V
QMCQ-VLOL Lower limit value of the mains voltage V
QMCQ-PLE Status of the active power-dependent reactive
power control hysteresis for QMCQ
Disabled/enabled
QMCQ-PLI Upper limit value of the active power W
QMCQ-PLO Lower limit value of the active power W
QMCPP
Reactive power mode "cosφ(Pac)"
-
QMCPP-PSP1…PSP10 Characteristic values 1 to 10 of Pac active power % of Pac nom
QMCPP-CPSP1…
CPSP10
Characteristic values 1 to 10 of power factor cosφ
- [UEX/OEX]
QMCPP-VLE Status of mains voltage-dependent reactive power
control hysteresis for QMCPP
Disabled/enabled
QMCPP-VLIH Upper limit value of the mains voltage V
QMCPP-VLOL Lower limit value of the mains voltage V
QMCCP
Reactive power mode "cosφ"
-
QMCCP-CPSV
cosφ value
- [UEX/OEX]
QMCCP-VLE Status of mains voltage-dependent reactive power
control hysteresis for QMCCP
Disabled/enabled
QMCCP-VLIH Upper limit value of the mains voltage V
QMCCP-VLOL Lower limit value of the mains voltage V
QMCCP-PLE Status of active power-dependent reactive power
control hysteresis for QMCCP
-
QMCCP-PLI Upper limit value of the active power W
QMCCP-PLO Lower limit value of the active power W
Reference parameters
Function / parameter Description Unit
NAP Rated output power (Pac nom) -
NAP-VAL Value W
NOC Rated output current -
NOC-VAL Value A
GCD Switching delay of the coupler breaker -
GCD-CDLY Tripping time s
