3 Production Information
■
Series Box
Left side view
i
ii iii
iv
v
Item No. Description
i HEAT: Connect to the “HEAT“ port of BMS
ii GND: Connect the grounding port to the grounding port of BMS
iii B-: Connect to the ”B-” of BMS
iv B+: Connect to the “B+“ of BMS
v COM: Connect to the “COM“ port of BMS
